38.00 $
Pick up from the Woodmart Store
To pick up today
Free
Courier delivery
Our courier will deliver to the specified address
2-3 Days
Free
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
Warranty 1 year
Free 30-Day returns
Payment Methods:
| Model Version | AP1200 1.0 | |
|---|---|---|
| CPU | CPU Details | 580 MHz Single-Core CPU |
| Memory/Storage | Flash/ROM | 16 MB (128 Mbit) NOR |
| DDR/RAM | 128 MB (1 Gbit) DDR2 | |
| Wireless | 5 GHz Wi-Fi Speed | 867 Mbps |
| 2.4 GHz Wi-Fi Speed | 300 Mbps | |
| 5 GHz Wi-Fi Streams | 2 Spatial Streams | |
| 2.4 GHz Wi-Fi Streams | 2 Spatial Streams | |
| Wi-Fi Antennas | 4× Internal | |
| FEM or PA/LNA | 5 GHz: 2× Internal, 2.4 GHz: 2× Internal | |
| Beamforming | ||
| Range Performance | Max: 170 m (558 ft) Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions. |
|
| Wall Performance | Two wooden walls with thickness < 10 cm (4”) One concrete wall with thickness < 20 cm (7”) |
|
| Interfaces | 10/100 Mbps RJ45 Ports | 1 |
| Ethernet Notes | ETH0: PoE In | |
| LED | System | |
| Physical Buttons | Reset Button | |
| Power | Power Input Type |
|
| Power Methods |
|
|
| Power Input |
|
|
| Max Power Consumption (W) | 12W | |
| Idle Power Consumption (W) | 2.5W | |
| Power Adapter In the Box | AP1200 | No adapter in the box AP1200P | PoE adapter in the box: Input: 100-240V~, 50/60Hz Output: 24V⎓ Passive PoE |
|
| Reliability | EMC | ESD: Contact: 4kV; Air: 8kV |
| Environment | Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing |
|
| Certifications | FCC, CE | |
| Mechanical | Installation |
|
| Dimension | Φ231.9×57.1 mm Φ9.13×2.25 inches |
|
| Product Weight |
|
|
| Package Content |
|
|
| Ordering Information | Retail Package Weight | EU: 720.3 g (25.41 oz.) |
| Retail Package Dimension | 283×238×68 mm 11.14×9.37×2.68 inches |
|
| Units per Carton | 20 | |
| Carton Net Weight | EU: 14.4 kg (31.75 lbs) | |
| Carton Gross Weight | EU: 15.5 kg (34.17 lbs) | |
| Carton Dimension | 58×37.5×49.5 cm 22.83×14.76×19.49 inches |
|
| Model Version | AP1200 1.0 | |
|---|---|---|
| Wireless | Wi-Fi Standards | Wi-Fi 5 |
| Max Wi-Fi Modulation | 256-QAM | |
| Wi-Fi Efficiency | MU-MIMO | |
| Wi-Fi Efficiency Note | MU-MIMO available on 5 GHz | |
| Max Capacity | 128 | |
| Recommended Client Upper Limit | 50 | |
| Wi-Fi Channel Width | Auto/20/40/80 MHz | |
| Wi-Fi Security | WPA/WPA2/WPA3 | |
| Guest Network | 2.4 GHz, 5 GHz | |
| WPS | ||
| General | Operation Modes |
|
| Mesh | Cudy Mesh | |
| Mesh Backhaul |
|
|
| Multi-Band Backhaul | ||
| WAN Mode |
|
|
| Internet Failover Sequence |
|
|
| Management | All Devices Management |
|
| Per-Devices Management |
|
|
| Content Management |
|
|
| Network | QoS | Per-User Rate Limiting |
| DHCP |
|
|
| IP Versions | IPv4/IPv6 | |
| IPv6 Protocols |
|
|
| Multicast | ||
| IPTV/VLAN | Tag VLAN | |
| TTL Customization |
|
|
| IGMP |
|
|
| Forwarding |
|
|
| Firewall |
|
|
| Application Layer Gateway |
|
|
| Utilities | Captive Portal | |
| Captive Portal Authentication | No Authentication, Local Password, External Portal Server | |
| VPN Server |
|
|
| VPN Client |
|
|
| DNS Options |
|
|
| DNS over TLS Providers |
|
|
| Wake on LAN | ||
| Online Detection | ||
| System | LED Control | |
| Local Control Method |
|
|
| Remote Control Method |
|
|
| Firmware Upgrade |
|
|
| Reliability |
|
|
| Diagnostic Tools |
|
|
| Languages |
|
|
| Dashboard | Panel |
|
| Charts |
|
|
